Fully Automatic Temperature Rise Test Device
RDTR-CB-7000A yog ib qho tseem ceeb, ntau yam khoom siv rau kev ntsuas kub tsis siv neeg nce siab hauv kev ntsuas hluav taws xob tam sim no. Zoo tagnrho rau HV switchgear thiab tsheb npav ducts, nws yog dav siv nyob rau hauv lub hwj chim, manufacturing, thiab R & D sectors, ua hauj lwm nyob rau hauv ib tug luv luv lub sij hawm los yog tsis sib xws.
RDTR-CB -7000A
TSEEM CEEB
RDTR-CB-7000Qhov Kev Ntsuas Kub Tsis Siv Neeg Tag Nrho Qhov Ntsuas Ntsuas Ntsuas Ntsuas yog ib qho tseem ceeb ntawm cov cuab yeej tsim los rau kev ntsuas tsis siv neeg thermal. Nws suav nrog lub kaw lus rau kev ntsuas qhov ntsuas kub ntawm qhov ntsuas kub, lub tshuab hloov pauv hloov pauv, hloov pauv qhov hluav taws xob induction hluav taws xob, thiab ntsuas qhov ntsuas kub zoo. Cov cuab yeej no yog qhov tseem ceeb hauv cov haujlwm uas qhov ntsuas hluav taws xob tam sim no yog qhov tseem ceeb. Nws ua hauj lwm raws li ib tug txheej txheem cuab yeej rau kev ntsuam xyuas lub thermal nce nyob rau hauv ib tug ntau yam ntawm high-voltage switchgear thiab busbar systems. Nws daim ntawv thov spans fais fab chaw nres tsheb, substations, tsim thiab kuaj chaw rau switchgear, hluav taws xob khoom factories, raws li zoo raws li kev tshawb fawb thiab chaw kuaj. Nws yog tsim los rau kev ua haujlwm uas luv luv lossis ncua sij hawm.
CHARACTERISTIC
1. Lub RDTR-CB-7000Ib suav nrog cov txheej txheem kev tiv thaiv xoom-pib rau thawj zaug kev ruaj ntseg.
2. Nws tso cai rau kev ywj pheej ntawm qhov kev xeem ncua sij hawm, ua tiav nrog lub sijhawm ceeb toom ua haujlwm rau kev tswj hwm kev sib tham.
3. Lub kaw lus tau tsim los kho qhov kev hloov pauv tam sim no nyob rau hauv qhov chaw, kom ntseeg tau tias kev ntsuas qhov tseeb.
4. Cov khoos phis tawj siab tshaj plaws muab cov ncauj lus kom ntxaws thiab meej ntawm cov khoom siv hluav taws xob thiab cov zis tawm tam sim no rau ib qho kev daws teeb meem 0.5.
5. Kev tswj hluav taws xob hluav taws xob yog tswj hwm hluav taws xob los tswj cov zis tam sim no, nrog kev tswj xyuas qhov tseeb kom haum rau ntau yam kev sim.
6. Kev ua haujlwm tau yooj yim los ntawm lub khoos phis tawj qib kev lag luam, siv lub tshuab ntse ntse tswj uas tshem tawm qhov xav tau ntawm cov txheej txheem kev xeem ntawv.
7. Cov Cuab Yeej Ntsuas Kub Ntsuas Ntsuas tsis tu ncua saib xyuas thiab nthuav tawm cov khoom siv hluav taws xob muaj txiaj ntsig thiab lub zog muaj zog hauv lub sijhawm tiag tiag rau kev tshuaj xyuas cov ntaub ntawv tam sim.
8. Raws li qhov ntsuas qhov ntsuas kub nce ntau thiab qhov cuam tshuam tsis zoo, lub cuab yeej cia li txhawb nqa lub teeb tso zis tam sim no, nruab nrog kev hloov kho rau kev kho qhov yuam kev tam sim no.
Peb Qhov Zoo
Tuam txhab Profile
Cim npe nrov: Tuam Tshoj tag nrho tsis siv neeg kub nce ntsuas ntsuas, Tuam Tshoj tag nrho tsis siv neeg kub nce ntsuas tshuab manufacturers, hoobkas
|
Qauv No |
RDTR-CB -7000A |
|
1. Ntaus yam tsis muaj |
|
|
Rated voltage |
380V |
|
Rated zaus |
50 Hz |
|
Hlau system |
Peb-theem plaub-hlau rwb thaiv tsev system; |
|
Tag nrho qhov system zog |
210 kW tsi |
|
Tag nrho qhov system tam sim no |
552.6A |
|
Qhov system fais fab |
cosΦ=0.8 |
|
Lub kaw lus los nrog cov khoom siv them nyiaj |
|
|
2. Roj-immersed induction voltage regulator |
|
|
Rated peev |
70kVA ua |
|
Output voltage adjustable ntau yam |
0-420 V |
|
Output tam sim no adjustable ntau yam |
0-166.6 A |
|
Voltage tswj hom |
hluav taws xob / phau ntawv |
|
Waveform distortion tus nqi |
Tsawg dua lossis sib npaug li 3% |
|
Pib voltage |
Tsawg dua lossis sib npaug li 1% |
|
luv Circuit Court impedance |
Tsawg dua lossis sib npaug li 7% (hauv qhov kev tswj hwm qhov hluav taws xob ntawm 50% txog 100%) |
|
Lub zog poob qis dua 1% thiab qhov ua tau zoo yog ntau dua 98%. |
|
|
3. Qhuav hom converter transformer |
|
|
Rated peev |
70kVA ua |
|
Output kab voltage |
10V |
|
Cov zis tam sim no |
0-7000A |
|
Tsis-load poob |
<4% |
|
Rated input voltage |
380V |
|
Rated input tam sim no |
184.2A |
|
Rated tso zis voltage |
10V |
|
Rated tso zis tam sim no |
7000A |
|
luv Circuit Court impedance |
Tsawg dua lossis sib npaug li 5% ntawm 0-7000A |
|
Cov zis hom |
ywj siab tso zis rau txhua theem |
|
Txoj kev ua kom txias |
qhuav, cua txias |
|
Lub sijhawm ua haujlwm |
Lub sijhawm ua haujlwm ntev ntawm qhov ntsuas voltage thiab ntsuas tam sim no. |
|
4. Console |
|
|
Nrog xoom pib tiv thaiv muaj nuj nqi |
|
|
Lub sij hawm xeem tuaj yeem teem rau ntawm nws tus kheej thiab muaj lub luag haujlwm ceeb toom |
|
|
Tom qab qhov tam sim no tau teeb tsa, deviations tuaj yeem hloov kho nyias |
|
|
Lub hwj chim mov thiab cov zis tam sim no tau tshwm sim los ntawm lub khoos phis tawj software nrog qhov tseeb ntawm 0.5 qib |
|
|
Hluav taws xob tswj qhov hluav taws xob nce thiab poob kom ua tiav cov zis tswj tam sim no, nrog kev xaiv tswj tau raug |
|
|
Industrial qib industrial computer tswj. Lub siab tsis siv neeg ntse tswj qhov system, tsis muaj kev cuam tshuam phau ntawv yuav tsum tau kuaj |
|
|
Lub kaw lus los nrog tus nqi hluav taws xob input thiab qhia lub zog ua haujlwm hauv lub sijhawm |
|
|
Tom qab teeb tsa qhov kub thiab txias ntau yam, cov cuab yeej cia li tswj cov zis tam sim no. Nws muaj cov haujlwm ntawm kev kho qhov yuam kev tam sim no |
|
|
Nws muaj 40 txoj hauv kev ntsuas kub, ntsuas, thiab kaw cov haujlwm, thiab tuaj yeem ntsuas qhov ntsuas kub ib puag ncig, sib piv qhov ntsuas kub ntawm qhov ntsuas ntsuas los ua qhov kub thiab txias, thiab tuaj yeem ceeb toom thaum ntsuas kub siab tshaj. Qhov ntsuas kub thiab qhov ntsuas kub nce ntawm txhua qhov chaw tuaj yeem rov qab tau, nrog kev ntsuas qhov yuam kev ntawm ± 1% |
|
|
Lub plhaub console yog ua los ntawm 2 hli txias-kuav los tiag steel phaj, hauv qab phaj yog thickened, thiab tag nrho cov khoom yog ruaj khov. Ob qho tib si sab hauv thiab sab nraud tau raug tshem tawm xeb thiab tiv thaiv xeb, electrostatically txau, thiab xim yog xiav thiab ntxhuav grey. |
|
|
Lub console teeb lub zog, pib, thiab xoom qhov taw qhia teeb nyob rau hauv cov xim daj, liab, thiab ntsuab feem |
|
|
Qhov tseeb theem ntawm transformer tam sim no yog 0.5 |
|
|
Lub console yog nruab nrog lub txee lub qhov rooj kom qhib tau yooj yim thiab kho cov cuab yeej siv. |
|
|
5. Insulating khoom |
|
|
Lub rwb thaiv tsev tiv thaiv ntawm qhov chaw nyob ntawm cov ncej sib txawv ntawm qhov ntsuas kub tsis siv neeg siab ntsuas ntsuas ntsuas hluav taws xob, thiab nruab nrab ntawm qhov chaw nyob ntawm txhua lub voj voog thiab hauv av, thaum qhov kub thiab txias yog +25 degree thiab av noo yog 45% rau 75%, yog ntau dua lossis sib npaug rau 100MΩ. |
|
|
6. Ib puag ncig tej yam kev mob |
|
|
Ambient kub |
-15 degree -+50 degree |
|
txheeb ze humidity |
Tsawg dua los yog sib npaug li 90% |
|
Qhov siab |
Tsawg dua los yog sib npaug li 1000m |
